Using Angular To Travel To The Other Side Of The World

With Angular, a tiny bit of math, Google Maps, and the OpenWeatherMap api, you can discover what it’s like on the exact other side of the globe.

Antipode

Index

The exact other side of the world from where you are right now is called your geographical antipode. For a bit of fun, I decided to make a simple Angular app in StackBlitz that retrieves your current location, then calculates your geographical antipode–the math is surprisingly simple–and then provides the weather for both, along with a small Google Maps image for both.

You can also enter custom coordinates for your starting position so you can discover the antipode for any place in the world!

NOTE: An antipode map. If you’re standing on a blue country, your antipode is the same country in yellow

Spoiler Alert:

If you’re in the lower 48 United States, then your antipode will place you in the middle of the Indian Ocean. We’ll ignore that unexciting fact for now… since we’ll show you ways to use it based on where you would like to be right now 🙂

Creating the app through StackBlitz

To start, go to stackblitz.com and select a new Angular project.

It should create a basic Angular app for you to modify:

Your app comes ready with an app component along with a hello component. We don’t need the hello component, but we will need a new “weather” component.

Remove the “Hello” Component

This is how you remove the “Hello” component:

Delete the hello.component.ts file.

Delete the “HelloComponent” references in app.module.ts

Delete the <hello> element in app.component.html

Refresh is necessary. Your app should have removed the “Hello Angular 12” at the top.

Add new Weather component

Right click on the “app” directory and select Angular Generator, then Component.

2. When it asks for a name, enter “Weather”

3. You’ll see that a new directory has been made with 3 files:

weather.component.css,
weather.component.html,
weather.component.ts.

These files make up your Weather component.

This new Weather component will display the weather information about your current location and your antipode.

Add Weather component to module

In app.module.ts, add WeatherComponent to declarations array next to AppComponent. Don’t forget to import it!

In app.component.html, add an element.

3. You should now see “weather works” in your results screen, indicating to us that the WeatherComponent has been successfully added.

Retrieve Current Location

Index

Retrieving your current location is surprisingly easy with the built-in navigator object in standard JavaScript.

1. In app.component.ts, replace your AppComponent class with this code:

export class AppComponent {
  lat: number;
  long: number;

  constructor() {
    this.getLocation();
  }

  getLocation(keepCoords?: boolean): void {
    if (navigator.geolocation) {
      navigator.geolocation.getCurrentPosition((position) => {
        this.lat = position.coords.latitude;
        this.long = position.coords.longitude;
      });
    } else {
      console.log('No support for geolocation');
    }
  }
}

This will cause getLocation to be called when the app loads and set two class properties, lat and long, to the latitude and longitude retrieve from the navigator object.

Bind class properties to UI inputs

There’s a chance the user won’t allow the code to retrieve its local position, or maybe the user wants to enter a custom location. We’ll give them the option by placing two inputs in the UI so they can enter whatever latitude and longitude they want, but default to their current location.

1. In app.component.html, remove the <p>…</p> element at the top and add these elements at the top instead:

Latitude:
<input [(ngModel)]="lat" />
Longitude:
<input [(ngModel)]="long" />

ngModel binds the lat and long properties to these inputs.

2. You should now be able to see your default coordinates!

Add parameters to weather app and display Google maps image

We’ve retrieved our local coordinates, but now we need to be able to use them to display something useful. We’re going to update our Weather component so it takes the latitude and longitude as parameters, pass those parameters to a Google maps url, and then embed that url into an iframe to display to the user.

1. Replace the code in weather.component.ts with this code which populates a property called “src” which we use to populate the iframe:

import { Component, Input, OnChanges } from '@angular/core';
import { DomSanitizer, SafeResourceUrl } from '@angular/platform-browser';

@Component({
  selector: 'app-weather',
  templateUrl: './weather.component.html',
  styleUrls: ['./weather.component.css'],
})
export class WeatherComponent implements OnChanges {
  @Input() lat: string;
  @Input() long: string;

  src: SafeResourceUrl;

  constructor(private sanitizer: DomSanitizer) {}

  ngOnChanges() {
    this.updateWeatherData();
  }

  updateWeatherData(): void {
    this.src = this.sanitizer.bypassSecurityTrustResourceUrl(
      `https://www.google.com/maps/embed?pb=!1m10!1m8!1m3!1d106203.97188628554!2d${this.long}00000002!3d${this.lat}!3m2!1i1024!2i768!4f13.1!5e0!3m2!1sen!2sus!4v1635881545400!5m2!1sen!2sus`
    );
  }
}

Note: when using a variable to bind to an iframe’s src property, Angular throws an error that the variable might be unsafe. We can bypass this by using Angular’s own DomSanitizer class and bypassSecurityTrustResourceUrl.

2. In app.component.html, add the lat and long parameters to the app-weather component. These will be populated with the values in the input fields:

<app-weather lat="{{ lat }}" long="{{ long }}"></app-weather>

3. Finally, in weather.component.html, replace the existing code with this:

<iframe
  [src]="src"
  width="300"
  height="225"
  style="border:0;"
  allowfullscreen=""
  loading="lazy"
></iframe>

Now we are using the “src” property from the WeatherComponent class we just created.

4. Now you should see the map centered on the location of your coordinates!

Calculate and Display Antipode

Index

Now that we’re displaying a slick google docs image of our current location, let’s take our coordinates and determine the antipode. The math is very simple: simply take the latitude and multiply it by -1, and then take the absolute value of the longitude and subtract it from 180:

New Latitude = Original Latitude * -1;
New Longitude = 180 – abs (Original Longitude);

The New Latitude and New Longitude give you the coordinates of your antipode!

1. In app.component.ts, add two new properties called anti_lat and anti_long:

anti_lat: number;
anti_long: number;

a. Add a new method for computing the antipode:

computeAntipode(): void {
    this.anti_lat = this.lat * -1;
    this.anti_long = 180 - Math.abs(this.long);
  }

b. Add a call to computeAntipode after retrieving and set the lat and long:

    this.lat = position.coords.latitude;
    this.long = position.coords.longitude;
    this.computeAntipode();

c. Add an onChange method that will recompute the antinode. The goal is tie this method to the change events in the original lat and long inputs:

onChange(e: any): void {
    this.computeAntipode();
  }

2. In app.component.html, add an ngModelChange event to the two inputs:

<input [(ngModel)]="lat" (ngModelChange)="onChange($event)" />
…
<input [(ngModel)]="long" (ngModelChange)="onChange($event)" />

3. In app.component.html, add the 2nd element at the end, passing in the anti_lat and anti_long for the parameters:

<app-weather lat="{{ anti_lat }}" long="{{ anti_long }}"></app-weather>

Now you should able to see the Google Maps image for your antipode!

The antipode for anywhere in the United States will be in the Indian Ocean

Displaying Weather Information

Index

Now that we’ve got a visual display, lets show some weather information like temperature, wind chill/heat index, sunrise, sunset, and time zone.

To display weather, I made a free account at https://openweathermap.org to use their simple one-call API. It returns data in this format:

Example of the JSON that will be returned when making a call to the OpenWeatherMap one-call-api.

1. In weather.component.ts immediately after the import statements, add a new Weather interface that is to contain the shape of the data we’ll be receiving from the api:

interface Weather {
  timezone: string;
  timezone_offset: number;
  current: {
    temp: number;
    feels_like: number;
    dt: number;
    currentTime: string;
    sunriseText: string;
    sunsetText: string;
    sunrise: number;
    sunset: number;
    wind_speed: number;
    weather: { main: string; description: string }[];
  };
}

Notice the addition of 3 new properties: currentTime, sunriseText, and sunsetText. This is because dt, sunrise, and sunset are all stored in number format when coming from the open weather api. We want to transform them into new, human-readable strings.

2. Then add a new weather property under the existing src property. This property will store the JSON data we receive from the open weather api:

  src: SafeResourceUrl;
  weather: Weather;

3. In order to call this api we’ll be using the Angular HttpClientModule. In app.module.ts, import HttpClientModule and then add it to the imports array:

…
import { HttpClientModule } from '@angular/common/http';

@NgModule({
  imports: [BrowserModule, FormsModule, HttpClientModule],
…

4. In weather.component.ts, import HttpClient and add it as a parameter to the constructor inside of WeatherComponent:

import { HttpClient } from '@angular/common/http';
…
…
constructor(private sanitizer: DomSanitizer, private http: HttpClient) {}

a. Because certain dates will come in UNIX format and we’ll want to convert them to human-readable code, lets add a method in the class to do that:

convertDate(unixDate: number): string {
    const date = new Date(unixDate * 1000);
    return date.toLocaleString();
  }

b. Then at the end of the updateWeatherData function, add this bit of code which calls the open weather api and transfers the data to the local weather property:

if (this.lat && this.long)
      this.http
        .get<Weather>(
          `https://api.openweathermap.org/data/2.5/onecall?lat=${this.lat}&lon=${this.long}&exclude=hourly,daily&appid=1a30e79ce8715662d0b2ddd6c6212fa6&units=imperial`
        )
        .subscribe((x) => {
          this.weather = {
            ...x,
            current: {
              ...x.current,
              sunriseText: this.convertDate(x.current.sunrise),
              sunsetText: this.convertDate(x.current.sunset),
              currentTime: this.convertDate(x.current.dt),
            },
          };
        });

5. In weather.component.html, before the iframe, add this code which will display weather data based on what’s in the weather class property:

<p>Temperature: {{ weather?.current?.temp }} F</p>
<p>Feels Like: {{ weather?.current?.feels_like }} F</p>
<p>Sunrise: {{ weather?.current?.sunriseText }}</p>
<p>Sunset: {{ weather?.current?.sunsetText }}</p>
<p>Time zone: {{ weather?.timezone }}</p>
<p>Weather: {{ weather?.current?.weather[0]?.main }}</p>

You should now be seeing weather for your location and your antipode!

And that’s it! Here’s a final version here: https://angular-ivy-lqwdux.stackblitz.io

Conclusion

If you’d like to see the coordinates for some popular places, please take a look at the list below. As you update the latitude and longitude, the Google Maps iframe and open weather api should automatically update:

City	Latitude	Longitude
Minneapolis, MN	45	-95
New York City, NY	40	-75
Asuncion, Paraguay	-25	-60
Rio De Janeiro, Brazil	-25	-45
Honolulu, HI	20	-160
Rome, Italy	40	10
London, England	50	0
Beijing, China	40	115

Index

Quick Menu

Antipode

Creating the app through StackBlitz

Retrieve Current Location

Calculate and Display Antipode

Displaying Weather Information

Conclusion

Get To Know Us

Author

by Luis Camacho III – Intertech, Inc. Consultant
